DANNOVO Outdoor 120m IR Medium Speed Dome PTZ CCTV Camera,18x,23x,30x,27x,Samsung 37x Optical Zoom(DN-CPTZ064M)
Main Features
DANNOVO Outdoor 120m IR Medium Speed Dome PTZ CCTV Camera,18x,23x,30x,27x,Samsung 37x Optical Zoom(DN-CPTZ064M):
Outdoor IR PTZ Medium Speed Dome PTZ CCTV Camera Features:
>>Horizontal Rotation Range:360o,Horizontal Rotation Speed:1～35°/S;
Tilt Rotation Range:90o,Tilt Rotation Speed: 30°/S;
>Optional Cameras: Dannovo,Samsung,Sony,CNB,LG,Hitachi;
>Auto Control IR LED:PWM Function,Intelligent IR Illumination & Power Consumption Is Variable,
Dependant Zoom Factor;
> IR Distance 120M; Multiple Languages For OSD Menu, English, Spanish Etc;
>Support Ambient Light Detection, IR Illumination On 1-15 Grades Selectable;
>Dome ID, Baud Rate, Communication Protocol Can Be Set Via The Controller;
>Supported Protocols: Pelco-D/P; Others On Special Request;
>7" Total Metal Body Construction, Waterproof IP66;
>Preset Points:220;Go To Preset Speed:01-64 Grades Selectable.
>4 Alarm Inputs and 2 Alarm Outputs Optional.
 |
 |
 |
|
 |
|||
| Optional Model NO. | Description | ||
| Dannovo 23x Zoom | 1/3" CCD, IR-CUT,EFFIO, 650TVLine,23x Optical Zoom | ||
| Dannovo 30x Zoom | 1/4" CCD, IR-CUT,EFFIO 4140+649, 650TVLine,30x Optical Zoom | ||
| Sony 18x Zoom | Sony FCB Ex-480cp, 18x Optical Zoom, D/N,1/4 type IT EX-VIEW HAD CCD 18X D/N f = 4.1 (WIDE) to 73.8 (TELE) mm, 550TVline | ||
| Samsung 27x Zoom | Samsung SCM-2271P,27x Optical Zoom D/N,1/4 inch, Super HAD color CCD 27X, f=3.5 to 94.5mm(F 1.6 to 2.9) ,560 TV Lines(Min.) : Color / 680 TV Lines(Min.) : B/W | ||
| Samsung 37x Zoom | Samsung SCM-3371P 37x Optical Zoom D/N/WDR,1/4 inch, Double density interline treneter CCD37X, f=3.5 to 129.5mm(F 1.6 to 3.9) 550 TV Lines(Min.) : Color / 680 TV Lines(Min.) : B/W |
Specifications
| Model No. | DN-CPTZ064M |
| Horizontal Rotation Speed | 1～35°/s |
| Tilt Rotation Speed | 30°/s |
| Horizontal Rotation Range | 360° |
| Tilt Rotation Range | 90o |
| Auto Flip | Horizontal 180°, Vertical 180° |
| Auto Control IR LED | PWM |
| Ratio Speed | Support |
| A-B Scan | User Programmable |
| A-B Scan Speed | 0-64 Levels Adjustable |
| Dwell Preset | 02-60s Interval Adjustable |
| Preset Points | 220 |
| Go To Preset Speed | 01-64 Levels Adjustable |
| Guard Tours | 3 Groups |
| Guard Points | Max.16 Points, Dwell Time User Selectable |
| Power On Action | Memory/No Action/A-B Scan/360° Scan/Home/Tour 1-3 |
| Park Time | 0-60 Mins Adjustable |
| Privacy Mask | Support (Only For Sony Camera, 24pcs ) |
| Alarm | Optional (4 Alarm Inputs And 2 Alarm Outputs) |
| OSD Menu | Multiple Languages |
| Ambient Light Detection | 0-50 Grades |
| IR Output Power | 4 Grades Adjustable |
| IR Standby Power | 4 Grades Adjustable |
| Communication Protocol | Pelco-D, Pelco-P |
| Communication | RS485 Bus |
| Baud Rate | 1200/2400/4800/9600bps |
| Operating Temperature | Indoor: 0°~ +40° Outdoor: -40°~ +60° |
| Operating Humidity | ≤95% Non Condensing |
| Heater & Blower | Auto Temperature Control |
| Power | AC/DC15-28V ≤3A (Standard Power: AC24V3A) |
| IR Illumination Distance | 120M |
| Power Consumption | ≤ 20W |
| Lightning Protection | Transient Voltage 6000V |
| Compatible Camera | China Dannovo,Samsung,Sony,CNB,LG,Hitachi |
| IR LED | ?20=6, ?16=5 |
