DANNOVO Variable Illuminant IR 120M Medium Speed Dome Outdoor PTZ Camera,18x,23x,37x,Samsung 27x Optical Zoom(DN-CPTZ069VIM)
Main Features
DANNOVO Variable Illuminant IR 120M Medium Speed Dome Outdoor PTZ Camera,18x,23x,37x,Samsung 27x Optical Zoom(DN-CPTZ069VIM):
Variable Illuminant IR Medium Speed Dome Camera Features:
>Variable Illuminant: IR Illumination Angle Variable From 5 Degrees To 60 Degrees;
>Medium Speed Dome PTZ Camera:Horizontal Rotation Range:360o,Horizontal Rotation Speed:100°/s;Tilt Rotation Range:93o,Tilt Rotation Speed:50°/s;
>Optional Cameras: Dannovo,Samsung,Sony,CNB,LG,Hitachi;
>PWM Function,Intelligent IR Illumination & Power Consumption Is Variable,Dependant Zoom Factor;
>IR Distance:120M; Multiple Languages For OSD Menu, English, Spanish Etc;
>Support Ambient Light Detection, IR Illumination On 1-15 Grades Selectable;
>Dome ID, Baud Rate, Communication Protocol Can Be Set Via The Controller;
>Supported Protocols: Pelco-D/P; Others On Special Request;
>7" Double Layers And Total Metal Body Construction, Waterproof IP66;
>Preset Points:220;Go To Preset Speed:01-64 Grades Selectable.
>4 Alarm Inputs and 2 Alarm Outputs Optional.
 |
 |
 |
|
 |
|||
| Optional Model NO. | Description | ||
| Dannovo 23x Zoom | 1/3" CCD, IR-CUT,EFFIO, 650TVLine,23x Optical Zoom | ||
| Sony 18x Zoom | Sony FCB Ex-480cp, 18x Optical Zoom, D/N,1/4 type IT EX-VIEW HAD CCD 18X D/N f = 4.1 (WIDE) to 73.8 (TELE) mm, 550TVline | ||
| Samsung 27x Zoom | Samsung SCM-2271P,27x Optical Zoom D/N,1/4 inch, Super HAD color CCD 27X, f=3.5 to 94.5mm(F 1.6 to 2.9) ,560 TV Lines(Min.) : Color / 680 TV Lines(Min.) : B/W | ||
| Samsung 37x Zoom | Samsung SCM-3371P 37x Optical Zoom D/N/WDR,1/4 inch, Double density interline treneter CCD37X, f=3.5 to 129.5mm(F 1.6 to 3.9) 550 TV Lines(Min.) : Color / 680 TV Lines(Min.) : B/W |
Specifications
| Model No. | DN-CPTZ069VIM |
| Horizontal Rotation Speed | 100°/s |
| Horizontal Rotation Range | 360° |
| Tilt Rotation Speed | 50o/s |
| Tilt Rotation Range | 93° |
| Auto Flip | Horizontal 180°, Vertical 180° |
| Auto Control IR LED | PWM |
| A-B Scan | User Programmable |
| A-B Scan Speed | 01-64 Level Setting Available |
| Dwell Preset | 01-60s Interval |
| Preset Points | 220 |
| Go To Preset Speed | 01-64 Level Setting Available |
| Guard Tours | 3 Groups |
| Guard Points | Max.16 Points, Dwell Time User Selectable |
| Park Time | 1-60mins Available |
| PWR On Action | Memory/No Action/A-B Scan/360° Scan/Home/Tour 1-3 |
| Park Mode | Off/A-B Scan/360° Scan/Home/Tour 1-3 |
| Communication Protocol | Pelco-D, Pelco-P |
| Communication | RS485 |
| Baud Rate | 1200/2400/4800/9600bps |
| Operating Temperature | -40°- +60° |
| Operating Humidity | ≤95% Non Condensing |
| Heater & Blower | Auto Temperature Control |
| Power | AC/DC15-28V ≤3A |
| IR Illumination Distance | 120M |
| Power Consumption | ≤ 20W |
| Lightning Protection | Transient Voltage 6000V |
| Compatible Camera | China Dannovo,Samsung,Sony,CNB,LG,Hitachi |
| LED Angle Of Illumination | 5-60 ° |
