DANNOVO 1080P 1080i 720P 10x Zoom HD PTZ Video Conferenceing Camera,Support HD-SDI or AV,DVI,HDMI,Ypbpr,and VGA(DN-HDC13)
Main Features
DANNOVO 1080P 1080i 720P 10x Zoom HD PTZ Video Conferenceing Camera,Support HD-SDI or AV,DVI,HDMI,Ypbpr,and VGA(DN-HDC13):
1080P 1080i 720P 10x Zoom HD PTZ Video Conferenceing Camera Features:
> HD 1/2.8 type Progressive CMOS Sensor, can Reach 2.7 Mega Pixel;
> 10x Optical Zoom;
> Supports HD-SDI and AV output alternative,DVI,Ypbpr,DVI-HDMI,and DVI to VGA output;
> Video Format:1080P/60, 1080P/50, 1080P/30, 1080P/25, 1080i/60, 1080i/50,720p/60,720p/50;
> Pan/Tilt: H: 0~355o,V: 120o;
> P/T Speed(P: 80°/ S T:60°/s);
> Wide-Angle: 65 °;
> Supports Images Flip Function;
> RS-232C/RS-422 Control(VISCA and PELCO-P/D);
> Support IR wireless remote control P/T/Z;
> 9 preset positions by remote commander, 255 preset positions by PC or keyboard controller, memory auto store when power off;
> VISCA and Pelco P/D protocol can be selected by code switch;
> Enter in and out menu by remote commander directly;
> Multi function Remote control;
> Mini Size: 135x130x140mm.
 |
 |
 |
|
 |
|||
1080P 1080i 720P 10x Zoom HD PTZ Video Conferenceing Camera Model NO. |
DN-HDC13 |
| Image Sensor | HD 1/2.8 Exmor CMOS |
| Effective Pixels | Approximately 2.7 Mega pixels(16:9) |
| Signal System(HD) | 1080P/60, 1080P/50, 1080P/30, 1080P/25, 1080i/60,1080i/50,720p/60,720p/50 |
| HD Video Output | HD-SDI(AV Output is Optional),DVI, Ypbpr, DVI to HDMI, DVI to VGA |
| Horizontal Viewing Angle | 65° |
| Focus system | Auto/Manual |
| Lens | 10x Optical Zoom, f=4.7mm(wide-angle)~47.0mm(far-end),F1.8~F3.0 |
| Minimum Illumination | 0.1Lux |
| Exposure Control | Auto/Manual/Priority AE/Exposure Compensation/ Bright |
| Shutter Speed | 1/30 ~ 1/10,000s |
| Gain | Auto/Manual |
| White Balance | Auto/ Indoor/Outdoor/One push Auto/Manual |
| S/N Ratio | ≥ 50dB |
| Pan/Tilt | Pan: +/- 355° (max. speed: 80°/s) Tilt: 120° (max. speed: 60°/s) |
| Preset Position | 9 by Remote,(255preset position by keyboard control) |
| Camera Control | RS-232C/RS-422 (VISCA) |
| Power | 10.8V～13.0V |
| Operating Temperature | 0℃～40℃ |
| Storage Temperature | -20℃～+60℃ |
| Consumption | 30W |
| Dimensions | (L)135×(W)130×(H)140mm |
| Weight | 768g |
