DANNOVO HD-SDI 1080P IR High Speed Dome PTZ Camera,MiNi Outdoor,China 10x Optical Zoom,360o Rotation(DN-SDIPTZ081IR)
Main Features
DANNOVO HD-SDI 1080P IR High Speed Dome PTZ Camera,MiNi Outdoor Dome Camera,China 10x Optical Zoom,360o Rotation(DN-SDIPTZ081IR):
HD-SDI IR High Speed Dome PTZ Camera Features:
>HD-SDI Digital Interface Output,1080P High Definition Image,Lie Transmission,No Delay;
>Horizontal Rotation Range:360o,Horizontal Rotation Speed:0.02~220°/s;Tilt Rotation Range:0°~93°,Auto Flip 180°,Tilt Rotation Speed: 0.02~100°/s;
>China 10x Optical Zoom;
>Video Output Format:1080P/30, 1080P/25, 720P/60, 720P/50;
>View Angle:52 degree, Focal Length: f=4.9-49MM, F1.6-F2.8;
>PWM Function, Intelligent IR Illumination & Power Consumption Is Variable,Dependant Zoom Factor;
>IR Distance:Up to 50M; Multiple Languages For OSD Menu, English, Spanish Etc;
>Support Ambient Light Detection, IR Illumination On 1-15 Grades Selectable;
>4.5" Total Metal Body Construction,Outdoor Use,IP66 Waterproof Grade;
>Dome ID, Baud Rate, Communication Protocol Can Be Set Via The Controller;
>Preset Points:220.
 |
 |
 |
|
 |
|||
| HD-SDI 1080P IR High Speed Dome PTZ Camera Model No.:DN-SDIPTZ081IR | |
| Camera | |
| Sensor | 1/2.7" Progressive Scan CMOS |
| Effective pixels | 1080P(1080X1920) |
| Total pixels | 2.0 Megapixels |
| Output Pixel | 1920*1080@30fps, 1920*1080@25fps, 1280*720@60fps, 1280*720@50fps |
| Lens | 10x Optical Zoom f=4.9mm(W) ~ 49mm(T) ±5% |
| Iris | F1.6 ~F2.8 |
| View of Angle | H:51.8°（W）~ 5.86°（T） V:39.1°（W）～4.4°（T） |
| Min. illumination | Color: 0.01 Lux \ B/W: 0 Lux |
| D/N | IR-CUT |
| BLC | Auto |
| WB | Auto |
| S/N Ratio | >50dB |
| Dome | |
| Pan range | 360°Continuous Rotation |
| Tilt range | 0°~93° Auto Flip 180° |
| Manual Pan speed | 0.02~220°/S |
| Manual Tilt speed | 0.02~100°/S |
| Preset Points | 220 |
| Pattern Scan | 4 groups |
| Guard Tours | 4 groups |
| Guard Points | Max.16 Points, Dwell time user selectable |
| Operating temperature | Indoor: 0°~ +40° Outdoor: -40°~ +60° |
| Operation menu | Multiple languages for OSD menu, English, Spanish etc |
| Pan and Tilt position display | Support |
| Humidity | ≤95% Non Condensing |
| Power | DC12V/ AC24V ≤3A |
| Consumption | < 25W |
| Lightning Protection | Transient voltage 6000V |
| Video interface output | SDI CVBS |
| Communication mode | RS485 (+/-) |
| Connection | Coaxial Cable |
| Size/Weight | 2.7KG（N.W）,3.4KG（G.W） |
| Related validation | IP66,CE,FCC,RoHs |
| IR parameters | |
| Auto Control IR LED | PWM |
| Support ambient light detection | IR illumination on 1-15 grades selectable; |
| LEDs | 4pcs |
| IR distance | up to 50 meters |
| Support ambient light detection | IR illumination on 1-9 grades selectable; |
